4.2 Interfaces and system functions
Availability of the interfaces
The following table shows the availability of the physical and logical interfaces. Note that in this
table all interfaces are listed. Depending on the system function, some interfaces are not
available. On the WBM pages you can only select the available interfaces.
We reserve the right to make technical changes.
Client Access point
W1748-1 M12 W1788-1 M12 W1788-2 M12
W1788-2 M12 EEC
W1788-2IA M12
Wireless interface
(WLAN)
WLAN 1
WLAN 1
WLAN 1
WLAN 2
LAN interface P1 LAN
P2 LAN PoE
P1 LAN
P2 LAN PoE
P1 LAN
P2 LAN PoE
VAP interface - VAP 1.Y
Y = 1 ... 8
VAP X.Y
X = 1 ... 2
Y = 1 ... 8
WDS interface - WDS 1.Y
Y = 1 ... 8
WDS X.Y
X = 1 ... 2
Y = 1 ... 8
VLAN 24 24 24
Availability of the system functions
The following table shows the availability of the system functions on the devices.
Technical basics
4.2 Interfaces and system functions
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
34 Configuration Manual, 11/2019, C79000-G8976-C485-03
