E.2 Parameters in Syslog messages
The Syslog messages can contain the following parameters:
Parameter Description Possible values or example
ip address IPv4 or IPv6 address IP address according to
RFC1035 or RFC4291 Sec‐
tion 2.2
src port
dest port
Port that is shown as decimal number.
Format: %d
0 ... 65535
client mac
dest mac
src mac
MAC address
Format: %02x:%02x:%02x;%02x:%02x:%02x
00:0C:29:2F:09:B3
protocol Name of the service that has generated this event
or of the Layer 4 protocol used.
Format: %s
Possible entries of:
UDP | TCP | WBM | Telnet |
SSH | Console | TFTP
| SFTP
group String that identifies the group based on its name
Format: %s
it-service
user name String that identifies the authenticated user based
on his/her name
without spaces
Format: %s
maier
action user name Identifies the user based on his/her name This is
not the authenticated user.
Format: %s
Peter.Maier
role Symbolic name for the group role
Format: %s
Administrator
time minute
timeout
Number of minutes
Format: %d
44
time second Number of seconds
Format: %d
44
failed login count Number of failed logins
Format: %d
10
max sessions Number of sessions
Format: %d
10
vap Symbolic name of the virtual access point interface
Format: (%s) or (%s %s)
VAP1.1
status reason Additional status information as legible string. It
can contain multiple words. The string must start
with " and end with " so that it can be analyzed.
(Invalid group cipher) (Un‐
known peer)
wlan interface Symbolic name of the WLAN interface
Format: %s
WLAN1
ssid SSID in ASCII representation
any number of spaces
Format: %s
MyWLAN
Appendix E
E.2 Parameters in Syslog messages
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
356 Configuration Manual, 11/2019, C79000-G8976-C485-03
