● Channel Width [MHz]
Shows the set channel bandwidth.
– 20 MHz
– 40 MHz (only with IEEE 802.11n/ac)
– 80 MHz or 160 MHz (only with IEEE 802.11ac)
● Connected BSSID
Shows the MAC address of the access point to which the client is connected.
● Connected SSID
Shows the SSID of the access point to which the client is connected.
● Security
Shows which authentication method is used.
If the authentication method "Open System + Encryption" or "Shared Key" is used,
"Encrypted (WEP/AES)" is displayed for both authentication methods.
● Context
Shows which security context is used.
● iFeatures
Shows which iFeatures are used.
– -
iFeatures are not used.
– iPRP
● Max. Data Rate [Mbps]
Shows the maximum data transmission speed in megabits per second.
● State
Shows the status of the WLAN interface.
– enabled
The WLAN interface is enabled.
– disabled
The WLAN interface is disabled.
6.4.16.3 Client List
Note
This WBM page is only available in access point mode.
Configuring with Web Based Management
6.4 "Information" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
122 Configuration Manual, 11/2019, C79000-G8976-C485-03
