● A-MSDU Packet Size [Bytes]
Specify the maximum size of the A-MSDU frame.
Range of values: 50 - 200 bytes
Default: 100 Bytes
● Guard Interval [ns]
Select the send pause that must be kept to between two transmitted OFDM symbols.
The following settings are possible. The selection depends on the selected transmission
standard.
– 400 (short)/800 (long): The setting 400 ns is optional. Depending on the signal quality,
packets can be sent with a send pause of 400 ns or 800 ns.
– 800 (long): The send pause is 800 ns.
Procedure
1. Enable the "A-MPDU" option.
2. Enter the required value in the "A-MPDU Limit [Frames]" input box.
3. Enable the "A-MSDU" option.
4. Enter the required value in the "A-MSDU Packet Size" input box.
5. Select the required value from the "Guard Interval [ns]" drop-down list.
6. Click the "Set Values" button.
6.6.2.6 Client
Connecting to a network
On this WBM page, you can specify how the device connects to a network as client.
Note
This WBM page is only available for clients or access points in client mode.
Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
238 Configuration Manual, 11/2019, C79000-G8976-C485-03
