Description
To restart the device, the buttons on this page provide you with the following options:
● Restart
Click this button to restart the system. You must confirm the restart in a dialog box. During
a restart, the device is reinitialized, the internal firmware is reloaded, and the device runs a
self-test. The learned entries in the address table are deleted. You can leave the browser
window open while the device restarts. You then need to log in again.
● Restore Memory Defaults and Restart
Click this button to restore the factory configuration settings with the exception of the
following parameters and to restart:
– IP addresses
– Subnet mask
– IP address of the default gateway
– DHCP client ID
– DHCP
– System name
– System location
– System contact
– User names and passwords
– Mode of the device
– DHCPv6 Rapid Commit
● Restore Factory Defaults and Restart
Click this button to restore the factory defaults for the configuration. The protected defaults
are also reset.
An automatic restart is triggered.
Note
By resetting all the defaults to the factory configuration settings, the IP address is also lost.
Following this, the device can only be accessed using the Primary Setup Tool or using
DHCP.
With the appropriate connection, a previously correctly configured device can cause
circulating frames and therefore the failure of the data traffic.
Configuring with Web Based Management
6.5 "System" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
150 Configuration Manual, 11/2019, C79000-G8976-C485-03
