The table has the following columns:
● Type
Shows the file type.
● Description
Shows the short description of the file type.
● Filename
A file name is preset here for every file type.
Note
Changing the file name
You can change the file name preset in this column. After clicking the "Set Values" button,
the changed name is saved on the device and can also be used with the Command Line
Interface.
● Actions
Select the action from the drop-down list. The selection depends on the selected file type,
for example you can only save the log file.
The following actions are possible:
– Save file
With this selection, you save a file on the SFTP server.
– Load file
With this selection, you load a file from the SFTP server.
Procedure
Loading or saving data using SFTP
1. Enter the address of the SFTP server in "SFTP Server Address".
2. Enter the port of the SFTP server to be used in "SFTP Server Port".
3. Enter the user data (user name and password) required for access to the SFTP server.
4. If applicable, enter the name of a file in which you want to save the data or take the data from
in "Filename".
Note
Files whose access is password protected
To be able to load these files on the device successfully, you need to enter the password
specified for the file in "System" > "Load&Save" > "Passwords".
5. Select the action you want to execute from the "Actions" drop-down list.
6. Click "Set Values" to start the selected action.
7. If a restart is necessary, a message to this effect will be output. Click the "OK" button to run
the restart. If you click the "Abort" button, there is no device restart. The changes only take
effect after a restart.
Reusing configuration data
Configuring with Web Based Management
6.5 "System" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
Configuration Manual, 11/2019, C79000-G8976-C485-03 163
