Description
Table 1 contains the following columns:
● Radio
Shows the available WLAN interfaces.
● Use Allowed Channels only
If you enable the option, you restrict the selection of channels via which the AP is allowed
to establish the connection.
In the following tables, you define which channels can use the AP to establish a wireless cell
with the channel setting "Auto".
The tables are divided up according to frequency bands.
If the option is disabled, the channels available based on the settings (country code,
antennas, transmit power etc.) are used.
Above the tables for the frequency bands, you will find the following check box:
● Select / Deselect all
– Enabled
If you enable the check box, all channels are selected.
– Disabled
If you deselect the check box, the first valid channel of the frequency band remains
enabled. Enable the required channel.
The tables of the frequency bands have the following columns:
● Radio
Shows the available WLAN interfaces.
● Radio Mode
Shows the mode.
● Channel number
To specify the valid channels for the required frequency band, select the appropriate check
box for the channel number.
The table displays the permitted channels of the country. Only the valid channels can be
enabled. Invalid channels are grayed out and cannot be enabled.
Note
To specify the channels, the setting "Use Allowed Channels only" must be enabled.
Procedure
1. Select the "Use Allowed Channels only" option for the required WLAN interface.
2. Deselect the check box "Select / Deselect all".
3. Select the relevant check box for the required channel number.
4. Click the "Set Values" button.
Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
236 Configuration Manual, 11/2019, C79000-G8976-C485-03
