6.4.6 Technical speci󹪝cations M5 R/L
Article number 6FB1103-0AT11-3MD0 6FB1103-0AT10-3MD0
General information
Product brand name SIDOOR
Product type designation M5 R M5 L
Product version With driven gear on the right With driven gear on the left
Supply voltage
Rated value (DC) 30 V
Input current
Operational current (rated value) 7.5 A
Power
Active power input 225 W
Mechanical data
Torque of the rotary operating mecha‐
nism (rated value)
6.8 N·m
Speed, max. 0.5 m/s
Gear ratio 15
Number of pulses per revolution, max. 100
Weight of door, max. 600 kg
Degree and class of protection
IP degree of protection
• of the motor
IP54
• of the gear unit
IP54
Standards, approvals, certi󹪝cates
CE mark Yes
UL approval Yes
EAC (formerly Gost-R) Yes
TÜV Inspectorate approval Yes
China RoHS compliance Yes
Ambient conditions
Ambient temperature during operation
• min.
-20 °C
• max.
50 °C
Ambient temperature during storage/
transportation
• Storage, min.
-40 °C
• Storage, max.
85 °C
Dimensions
Height of motor 124 mm
Length of motor 344 mm
Diameter of motor 80 mm
Width of gear unit, including drive pinion 111 mm
Geared motors
6.4 Technical speci󹪝cations
ATD4xxW for industrial applications
220 System Manual, 06/2022, A5E51901827B AA
