Note
The terminal module function is also available via the SIDOOR SOFTWARE KIT.
3.2.5 Accessories
Accessories Article No. Description
SIDOOR rubber-metal anti-vibra‐
tion mount
6FB1104-0AT01-0AD0
• Rubber-metal anti-vibration mount for quiet operation
of the door drive system
• Recommended for mounting SIDOOR M4 R / L, MDG4
R / L, M5 R / L and MDG5 R / L geared motors
6FB1104-0AT02-0AD0
• Rubber-metal anti-vibration mount for quiet operation
of the door drive system
• Recommended for mounting SIDOOR M3 R / L and
MDG3 R / L geared motors
SIDOOR MDG-PULLEY 10-
S8M-56
6FB1104-0AT10-0AS1 Belt pulley MDG PULLEY for DC geared motor MDG3 and
toothed belt S8M, pitch diameter 56 mm
SIDOOR MDG PULLEY 14-
S8M-56
6FB1104-0AT14-0AS1 Belt pulley MDG PULLEY for DC geared motor MDG4, MDG5
and toothed belt S8M, pitch diameter 56 mm
SIDOOR mounting bracket 6FB1104-0AT01-0AS0 Mounting bracket for mounting the SIDOOR rubber-metal
anti-vibration mount on which, in turn, a SIDOOR geared
motor is mounted
6FB1104-0AT02-0AS0
• Mounting bracket with tensioning device for de󹪞ector
pulley
• For mounting the SIDOOR de󹪞ector unit and for ten‐
sioning the SIDOOR toothed belt
SIDOOR de󹪞ector pulley 6FB1104-0AT04-0AS2 De󹪞ector pulley for de󹪞ecting the SIDOOR toothed belt (1
unit)
SIDOOR de󹪞ector unit 6FB1104-0AT03-0AS0
• De󹪞ector unit with de󹪞ector pulley
• For de󹪞ecting the SIDOOR toothed belt in the same
height and depth, aligned with motor drive pinion
SIDOOR door clutch holder 6FB1104-0AT01-0CP0
• Door clutch holder for 12 mm-wide toothed belt
• For attaching both ends of the toothed belt, and for
connecting the respective door panel to the toothed belt
6FB1104-0AT02-0CP0
• Door clutch holder for 14 mm wide toothed belt
• For attaching both ends of the toothed belt, and for
connecting the respective door panel to the toothed belt
