6.4.22 Dimension drawing of door clutch holder
Security screw M6
Clamping plate
STS timing chain
Bracket nosing
Security screw
Door clutch holder
No supply
Clamping plate
Bracket nosing
STS timing chain
Figure 6-15 Door clutch holder
Geared motors
6.4 Technical speci󹪝cations
ATD4xxW for industrial applications
System Manual, 06/2022, A5E51901827B AA 233
