6. The display on the control unit is as follows:
– The 7-segment display (H401) shows "H.". The decimal point in the 7-segment display
(H401) 󹪞ashes during the save process.
The 7-segment display (H401) shows "u" when saving has 󹪝nished. If a light barrier /
pressure sensitive edge (SIDOOR ATD4xxW) is used, the 7-segment display (H401) shows
"O." because X6 is not connected yet.
For the M3, M4 and M5 motors, the determined door width is shown on the LCD for the
󹪝rst commissioning or motor adaptation.
– The LCD display (H1) shows "'H': learn run activated".
7. The door can now be opened with the OPEN button (S402).
– The 7-segment display (H401) shows "o" while the door is opening.
8. Switch o󹪜 the control unit by pulling out the power plug or the connector X3.
10.5 Connecting digital inputs
Connecting digital inputs
Connecting digital input signals
1. Insert the terminal connectors for the digital control inputs in X6, X5 and X4. See
section Digital input signals (Page 132) for more on this.
Note
Risk of injury through moving mechanical parts.
The controller will be operative after the next switch-on. If a control signal is present, the
door will move in the set direction.
2. Select the FBLOCK con󹪝guration according to the wiring of the input signals via the service
menu. See section Digital input signals (Page 132) for more on this.
10.6 Commissioning the control unit on the 󹪝eldbus
Introduction
If your controller is equipped with a PROFIBUS or PROFINET module, you can operate the
controller at the respective 󹪝eldbus with a higher-level controller.
The following procedure describes how to commission a SIDOOR control unit on the respective
󹪝eldbus.
Connecting and commissioning
