5.8 Technical speci󹪝cations
Technical speci󹪝cations
Article number 6FB1141-1AT11-3W
E2
6FB1141-2AT10-3W
E2
6FB1141-3AT10-3W
E2
General information
Product brand name SIDOOR
Product type designation ATD401W ATD420W ATD430W
Product version With relay outputs With PROFIBUS inter‐
face
With PROFINET inter‐
face
Optional product expansion TRANSFORMER (6FB1112-0AT20-2TR0), TRANSFORMER UL
(6FB1112-0AT21-2TR0), NT40 (6FB1112-0AT20-3PS0), DIN rail hold‐
er (6FB1144-0AT00-3AS0)
Manufacturer's article no. of
the usable motor
6FB1103-0AT10-4MB0, 6FB1103-0AT10-3MC0,
6FB1103-0AT10-3MD0, 6FB1103-0AT11-4MB0,
6FB1103-0AT11-3MC0, 6FB1103-0AT11-3MD0,
6FB1103-0AT14-4MB1, 6FB1103-0AT13-4MB1,
6FB1103-0AT14-3MC2, 6FB1103-0AT13-3MC2,
6FB1103-0AT14-3MG2, 6FB1103-0AT13-3MG2
Manufacturer's article no. of
the usable power supply unit
6FB1112-0AT20-2TR0, 6FB1112-0AT21-2TR0,
6FB1112-0AT20-3PS0, 6EP3446-8SB10-0AY0
Installation type/mounting
Installation and mounting in‐
structions
No direct solar radiation, 󹪝nal application-speci󹪝c requirements must
be observed. Installation outside a control cabinet only in horizontal
mounting position
Supply voltage
Design of the power supply Via SIDOOR TRANSFORMER / SIDOOR TRANSFORMER UL / NT40 / SI‐
TOP PSU8200 13 A, 36 V or via DC
Rated value (DC) 36 V
permissible range, lower limit
(DC)
19.2 V
permissible range, upper limit
(DC)
38 V
Protection in case of DC supply Use of a circuit breaker in the supply path according to 60898-1, 8A,
C-characteristic type SIEMENS: 5SY4108-7 or 5SY4108-7KK11
Input current
I²t, min. 30 A²·s
Encoder supply
Output voltage (DC) 24 V; Ensure correct polarity! CAUTION: Do not supply with external
voltage!
short-circuit proof Yes
Overload-proof Yes
24 V encoder supply
• Output current, max.
400 mA
Power
Active power input 145 W
Active power input, max. 540 W
Controllers
