7.4.3 Technical speci󹪝cations
Core statement
Order number 6EP3446-8SB10-0AY0
Product SITOP PSU8200
Power supply, type 36 V/13 A
Input
Input 3-phase AC
Rated voltage value Vin rated 400 ... 500 V
Voltage range AC 320 ... 575 V
Wide-range input Yes
Mains bu󹪜ering at Iout rated, min. 15 ms; at Vin = 400 V
Rated line frequency 1 50 Hz
Rated line frequency 2 60 Hz
Rated line range 47 ... 63 Hz
Input current
• at rated input voltage 400 V
1.2 A
• at rated input voltage 500 V
1 A
Switch-on current limiting (+25 °C), max. 16 A
I²t, max. 0.8 A²·s
Built-in incoming fuse none
Protection in the mains power input (IEC 898) Required: 3-pole connected miniature circuit break‐
er 6 ... 16 A characteristic C or circuit breaker
3RV2011-1DA10 (setting 3 A) or 3RV2711-1DD10
(UL 489)
Output
Output Controlled, isolated DC voltage
Rated voltage Vout DC 36 V
Total tolerance, static ± 3 %
Static mains compensation, approx. 0.1 %
Static load balancing, approx. 0.2 %
Residual ripple peak-peak, max. 100 mV
Spikes peak-peak, max. (bandwidth: 20 MHz) 200 mV
Adjustment range 36 ... 42 V
Product function Output voltage adjustable Yes
Output voltage setting via potentiometer; max. 480 W
Status display Green LED for 36 V OK
Signaling Relay contact (NO contact, rating 60 V DC/ 0.3 A)
for 36 V OK
On/o󹪜 behavior No overshoot of Vout (soft start)
Startup delay, max. 2.5 s
Voltage increase time of the output voltage max‐
imum
500 ms
Rated current value Iout rated 13 A
Current range 0 ... 13 A
Power supply
7.4 SITOP PSU8200 13A/36V 3-phase
ATD4xxW for industrial applications
System Manual, 06/2022, A5E51901827B AA 261
