Article number 6FB1112-0AT21-2TR0
Standard for safety UL 61010-1, CSA C22.2 No. 61010-1-12, Low Volt‐
age Directive (LVD) 2014/35/EU
Ambient conditions
Ambient temperature during operation
• min.
-20 °C
• max.
55 °C
• Remark
No direct exposure to the sun
Ambient temperature during storage/transpor‐
tation
• Storage, min.
-20 °C
• Storage, max.
70 °C
• Transportation, min.
-40 °C
• Transportation, max.
70 °C
Altitude during operation relating to sea level
• Installation altitude above sea level, max.
2 000 m
Relative humidity
• No condensation, min.
10 %
• No condensation, max.
93 %
Cables
Cable length
• Input side
2 m
• Output side
1.5 m
Connection method
Design of electrical connection at input equipped with ferrules
Dimensions
Width 145 mm
Height 65 mm
Depth 126 mm
Power supply
7.3 SIDOOR TRANSFORMER UL
ATD4xxW for industrial applications
System Manual, 06/2022, A5E51901827B AA 257
