Order number 6EP3446-8SB10-0AY0
Product SITOP PSU8200
Power supply, type 36 V/13 A
Leakage current
• maximum
3.5 mA
• typical
0.9 mA
CE mark Yes
UL/cUL (CSA) approval cULus-Listed (UL 508, CSA C22.2 No. 107.1), File
E197259
Explosion protection No
FM approval -
CB approval Yes
Marine approval GL, ABS
Degree of protection (EN 60529) IP20
EMC
Emitted interference EN 55022 Class B
Supply harmonics limitation EN 61000-3-2
Noise immunity EN 61000-6-2
Operating data
Ambient temperature
• during operation
-25 ... +70 °C
– Note
with natural convection
• during transport
-40 ... +85 °C
• during storage
-40 ... +85 °C
Humidity class according to EN 60721 Climate class 3K3, no condensation
Mechanics
Connection technology screw-type terminals
Connections
• Supply input
L1, L2, L3, PE: 1 screw terminal each for 0.2 ... 4
mm² single-core/nely stranded
• Output
+, -: 2 screw terminals each for 0.2 ... 4 mm²
• Auxiliary
13, 14 (alarm signal): 1 screw terminal each for
0.14 ... 1.5 mm²; 15, 16 (Remote): 1 screw terminal
each for 0.14 ... 1.5 mm²
Width of the enclosure 70 mm
Height of the enclosure 125 mm
Depth of the enclosure 125 mm
Required spacing
• top
50 mm
• bottom
50 mm
• left
0 mm
• right
0 mm
Weight, approx. 1.2 kg
Product feature of the enclosure housing for side-
by-side mounting
Yes
Power supply
7.4 SITOP PSU8200 13A/36V 3-phase
ATD4xxW for industrial applications
System Manual, 06/2022, A5E51901827B AA 263
