Action Key Remarks
5
• Select the next parameter
(Step 1)
or
-
• Exit the menu
Note
Parameter changes are accepted with the door at a complete stop or in the OPEN or CLOSED
position.
WARNING
Risk of injury due to moving mechanical parts
The permissible energies, forces and safety-related functions such as light barriers, emergency
stop or two-hand operation must be checked by the service personnel after changing the
parameters on the door in the overall system.
Menu navigation
The menu-based operation of the SIDOOR SERVICE TOOL is described in the section Navigation
structure SIDOOR SERVICE TOOL (Page 274).
Optional additional units
8.1 SIDOOR SERVICE TOOL
ATD4xxW for industrial applications
System Manual, 06/2022, A5E51901827B AA 273
