Structure
The IND array (parameter index) is subdivided as follows:
Table A-5 IND structure
IND
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Page index x x IND subindex
IND subindex
The IND subindex array is an 8-bit value that is transferred in the low byte (bits 0 to 7) of the (IND)
parameter index. In the PROFIBUS "variable-speed drives" pro󹪝le, the subindex 󹪝eld is simply
named "Subindex".
Parameter page index
The page index is used to select parameter pages. This enables the PNU value range to the
extended (0 to 1999). The resulting parameter ID then has the value range from 0 to 65,999.
The page index is coded in bits 10 to 15 of the high byte of IND.
Bits 8 and 9 are reserved, and not used.
The page index is de󹪝ned as multiple of 2000. The binary representation is also scrambled. The
exact assignment of the bits is described below.
Table A-6 Parameter page index
IND
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
a d c b f e
Table A-7 Page index assignment
Value range of parameter ID Bits for page index Hex val‐
ue
+ parameter number (PNU)
from to a d c b f e
0000 1999 0 0 0 0 0 0 0x00 0x0000 to 0x07CF
2000 3999 1 0 0 0 0 0 0x80 0x0000 to 0x07CF
4000 5999 0 0 0 1 0 0 0x10 0x0000 to 0x07CF
6000 7999 1 0 0 1 0 0 0x90 0x0000 to 0x07CF
8000 9999 0 0 1 0 0 0 0x20 0x0000 to 0x07CF
… … … … … … … … …
32,000 33,999 0 0 0 0 0 1 0x04 0x0000 to 0x07CF
… … … … … … … … …
64,000 65,999 0 0 0 0 1 0 0x08 0x0000 to 0x07CF
