The respective checksums can also be read out via the service menu.
Parameter Meaning Included in
default
checksum
(r200)
Included in
learn run
checksum
(r201)
Change
counter
default
parame‐
ter
(r202)
p90 Write protection No No +1
p91 Reset to factory settings Yes Yes Set to "0"
p92 Reset FBLOCK parameter set to factory settings (com‐
mand parameters)
No No 0
p93 Load factory settings of the driving curve parameter set No No +1
p95 Activation of a test run No No 0
p100 Default command mode Yes No +1
r200 – r202 Checksums/change counters of the parameters (ReadOn‐
ly) (new)
No No 0
p1200 – p1242 Calibration and function parameters Yes No +1
p1250 – p1252 Calibration and function parameters for old calibration
functions
Yes No +1
p2020 – p2023 Fieldbus communication channel parameters No No 0
p2040 Fieldbus monitoring time for the master monitoring Yes No +1
p2080 – p2081 DCMD 󹪝eldbus/ext.DCMD 󹪝lter Yes No +1
p2101 – p2111 Calibration and function parameters - basic parameters No Yes 0
p2200 – p2205 Parameters for position block Yes No +1
p3660 – p3685 Driving parameters Yes No +1
p3686 – p3689 Parameters for reduced door range of motion Yes No +1
p3850 – p3885 Obstruction and reversing parameters Yes No +1
p4600 Local sensor type Yes No +1
p4601 Discrepancy time in the function test of the OSSD system Yes No +1
p4602 Output transmission Yes No +1
p4610 – p4611 Discrepancy analysis times (AND0 and AND2) Yes No +1
p4700 – p4702 Fieldbus value selection for cyclic transfer of process val‐
ues
No No 0
p20000 – p20030 FBLOCK DCMD Yes No +1
p20057 – p20060 FBLOCK DCMD for old calibration functions Yes No +1
p20100 – p20122 FBLOCK REF Yes No +1
p20127 – p20130 FBLOCK REF for old calibration functions Yes No +1
Validity of checksums
If parameters were changed and not yet stored retentively, parameter r204 returns the value 0
(checksum invalid) and the parameter checksums r200 and r201 also have the value 0.
When the retentive storage of the parameters is 󹪝nished, parameter r204 returns the value 1 and
the parameter checksums r200 and r201 have a value unequal to 0.
SIDOOR functions
4.2 System functions
ATD4xxW for industrial applications
78 System Manual, 06/2022, A5E51901827B AA
