Cable temperature
Note that the temperature properties of the cables must correspond to the actual measured
temperatures:
● When a temperature of 70 °C is reached on the cable or at the cable entry of the housing
under operating conditions.
● When the temperature at the wire junction can be > 80 °C under operating conditions.
You specify other connection types and material requirements based on the following:
● Electrical characteristic data of the circuits you are using
● Installation environment
See also
Rules for the operation (Page 23)
12.1.6 Specifications for insulation tests, protection class and degree of protection
Test voltages
Table 12-16 Test voltages
Circuits with a rated voltage of U
e
relative to other
circuits or ground
Test voltage
0 V < U
e
≤ 50 V 500 V AC, 60 s
Protection class
Protection class I in compliance with IEC 61140; this means that a grounding terminal to the rail
is required!
Protection against foreign bodies and water
Protection class IP 20 according to IEC 60529; that is protection against contact with standard
probes.
There is no protection from penetration by water.
Technical specifications
12.1 General technical specifications
SIMATIC CFU
164 Commissioning Manual, 08/2019, A5E39252870-AD
