Additional information
For additional information on the topics intrinsic safety and explosion protection please refer to:
● Automation Systems S7-300, ET 200M Ex I/O Modules manual (
https://
support.industry.siemens.com/cs/ww/en/view/1096709)
●
Investigation of intrinsic safety for field bus systems
; PTB Report W-53, Braunschweig,
March 1993
●
PROFIBUS PA Commissioning Guide
, Notes on using the IEC 61158-2 technology for
PROFIBUS, (German art. no. 2.091 , English art. no. 2.092)
PROFIBUS-Nutzerorganisation e. V. (http://www.profibus.com)
A.8 Using a SIMATIC Compact Field Unit with GSDML
This document contains information on using the SIMATIC Compact Field Unit at Integration
through GSDML.
Note the following restrictions compared to integration of the CFU when using SIMATIC PCS 7
V9.0 or higher.
● General (Page 191)
● DI/DO; Counter; Measure frequency (Page 192)
● CFU PA only: CFU PA and field devices (Page 192)
A.8.1 General
● Replacing bus adapter
The bus adapter must be replaced in two steps (each port separately). Only related port
pairs may be replaced.
● Replace Object
Objects (modules, submodules) cannot be replaced
● Firmware update
Use the firmware update function of your engineering system for the firmware update.
The firmware update is possible with standard SIMATIC mechanisms.
A firmware update can take a longer period.
CFU PA
Note
Read back parameters
The "Read back IOs" function is not available.
Appendix
A.8 Using a SIMATIC Compact Field Unit with GSDML
SIMATIC CFU
Commissioning Manual, 08/2019, A5E39252870-AD 191
