Rule for ... Connections PS<n> Connections FB<n> and DIQ<n>
Permitted cable
cross-sections for
flexible cables
Without ferrule 0.2 to 2.5 mm
2
AWG
*
: 24 to 13 AWG*: 24 to 14
With ferrule (with plastic sleeve)
***
0.25 mm to 1.5 mm
2**
0.14 mm to 1.5 mm
2
AWG
*
: 24 to 16 AWG
*
: 26 to 16
With TWIN ferrule
***
0.5 mm to 1 mm
2
0.5 to 0.75 mm
2
(see below)
AWG
*
: 20 to 17 AWG
*
: 20 to 18
Stripped length of the cables 7 to 10 mm
Wire end ferrules in accordance with DIN 46228 with
plastic sleeve
***
7 and 10 mm long
* AWG: American Wire Gauge
** Ferrules without plastic sleeve: 0.25 to 2.5 mm
2
/AWG: 24 to 13
*** See note on ferrules
Note
Ferrules
You can achieve optimum results with respect to a high-quality and durable electrical
connection with maximum conductor extraction forces through the use of crimp shapes,
preferably with smooth surfaces, as is ensured for example with rectangular and trapezoidal
crimp cross-sections.
Due to the variety of crimp shapes used in industry, we recommend other shapes on request.
Crimping dies with a pronounced wave profile are unsuitable.
A.5 Dimensional diagrams
A.5.1 Dimension drawings of the mounting rails
Dimensions for the drill holes
Mounting rails can be ordered in the lengths 483 mm and 2000 mm.
Appendix
A.5 Dimensional diagrams
SIMATIC CFU
Commissioning Manual, 08/2019, A5E39252870-AD 187
