Article number 6ES7655-5PX11-1XX0
General information
Product type designation Compact Field Unit
HW functional status FS02
Firmware version V1.2
● FW update possible
Yes
Vendor identification (VendorID) 002AH
Device identifier (DeviceID) 060DH
Number of channels 16
Product function
● I&M data
Yes; I&M0 to I&M4
● The user can configure digital channels as
input/output as required
Yes
● Digital channels can be parameterized
Yes
Engineering with
● STEP 7 TIA Portal configurable/integrated
as of version
- / -
● STEP 7 configurable/integrated as of version
V5.6 HF2 and higher
● PCS 7 configurable/integrated as of version
V9.0 SP2 and higher
● PROFIBUS as of GSD version/GSD revision
- / -
● PROFINET as of GSD version/GSD revision
GSDML V2.3
Operating mode
● Counter
Yes
Installation type/mounting
Mounting on 35 mm DIN rail, 2 spacing units wide
Mounting position Horizontal, vertical
Supply voltage
Type of supply voltage 24 V DC
Rated value (DC) 24 V
permissible range, lower limit (DC) 19.2 V
permissible range, upper limit (DC) 28.8 V
Reverse polarity protection Yes
Short-circuit protection Yes
Redundant power supply Yes
Mains buffering
● Mains/voltage failure stored energy time
5 ms; Bridging for field devices and communication
Input current
Current consumption (rated value) 2.5 A
Current consumption, max. 2.55 A
Inrush current, max. 8 A
I²t 0.3 A²·s
Encoder supply
Number of outputs 8
Output voltage encoder supply, min. 18.2 V
Technical specifications
12.2 Technical specifications of the Compact Field Unit PA
SIMATIC CFU
166 Commissioning Manual, 08/2019, A5E39252870-AD
