Technical specifications
Article number 6ES7655-5PX31-1AX0
Installation type/mounting
Mounting position Horizontal, vertical
Recommended mounting position horizontal set up
Degree and class of protection
Degree of protection acc. to EN 60529
● IP66
Yes
Ambient conditions
Ambient temperature during operation
● horizontal installation, min.
-40 °C
● horizontal installation, max.
60 °C; Max. 4 A load current; up to 50 °C max. 5 A
load current
● vertical installation, min.
-40 °C
● vertical installation, max.
50 °C
Ambient temperature during storage/transporta‐
tion
● min.
-40 °C
● max.
70 °C
Dimensions
Width 414 mm
Height 266 mm
Depth 111 mm
Weights
Weight, approx. 5.5 kg
Observe the following sections:
● Section "Mechanical and climatic ambient conditions for operation (Page 160)"
● Section "Technical specifications of the Compact Field Unit DIQ (Page 173)"
Cable glands
You can find information on the following cable glands in the section"Tools and tightening
torques (Page 186)".
● Cable glands
● Cap nut
● Pressure compensation element
Technical specifications
12.5 Technical specifications of the SIMATIC CFU DIQ with aluminum housing
SIMATIC CFU
180 Commissioning Manual, 08/2019, A5E39252870-AD
