When you select the function ’Settings’ in the ’Tools’ menu, a dialog box
(see Figure 4-8) will appear in which you can input stipulations and rules
regarding layout, dimensions, zoom, colors and fonts of the SFC elements.
Settings
FilesGeneral Layout Dimensions Zoom Colors Font
D
efault
version:
Substructure le
vels:
Delete substructures autom
atically
Load plant data only when required
Plausibility test: Always display warnings
Report opening of read-only recipes
OK Cancel Help
V1.0
5
Figure
4-8
’Settings’ dialog box with default ’General settings’
The default version for new recipes can be specified here.
Substructure levels:
Here you can specify the maximum number of substructure nesting levels.
The other settings are self-explanatory.
Alignment:
You can specify that the SFC alignment of the recipe be left aligned, centered
or right aligned. If you want to align a particular recipe differently, you can
do this via the ’View’ menu.
AF/transition:
The following types of presentation are available
– Block
– Rectangle
– Rectangle with shadow
– Button
