4-1
Batch
flexible
, Manual
C79000-G7076-C650-02
Recipe creation
This chapter provides a description of the recipe editor and control recipe
generator applications. Together with the BOM the two applications
constitute the basis for all other BATCH flexible applications.
Recipe creation is concerned with creating recipes on the basis of automation
functions which with the aid of SFC (in accordance with DIN/IEC 1131) are
put together graphically using a recipe editor.
This chapter also deals with the user interface and the philosophy behind
operator control and recipe creation.
This chapter deals with the following topics:
Chapter Topic Page
4.1 Tasks of recipe creation 4-3
4.2 Description of the recipe 4-4
4.3 Starting the program 4-7
4.3.1 User interface 4-10
4.4 Handling recipes 4-16
4.4.1 Creating and opening recipes 4-17
4.4.2 Configuring recipes 4-18
4.4.3 Specifying recipe properties 4-30
4.4.4 Saving recipes, saving as, checking
plausibility
4-36
4.4.5 Status of the recipes and state transitions 4-37
4.4.6 Releasing a recipes and printing 4-38
4.5 Control recipe generator 4-39
Overview
In this chapter
4
