6 NC Machine Data (NC MD), NC Setting Data (NC SD) 09.95
6.2 General machine data (general data)
1st transformation, parameters 1 to 10*
730 - 739
Default value Lower input limit Upper input limit Units
0 -99 999 999 99 999 999 units (IS)
Active on
Power On
2nd transformation, parameters 1 to 10
740 - 749
Default value Lower input limit Upper input limit Units
0 -99 999 999 99 999 999 units (IS)
Active on
Power On
3rd transformation, parameters 1 to 10
750 - 759
Default value Lower input limit Upper input limit Units
0 -99 999 999 99 999 999 units (IS)
Active on
Power On
4th transformation, parameters 1 to 10
760 - 769
Default value Lower input limit Upper input limit Units
0 -99 999 999 99 999 999 units (IS)
Active on
Power On
5th transformation, parameters 1 to 10
770 - 779
Default value Lower input limit Upper input limit Units
0 -99 999 999 99 999 999 units (IS)
Active on
Power On
6th transformation, parameters 1 to 10
780 - 789
Default value Lower input limit Upper input limit Units
0 -99 999 999 99 999 999 units (IS)
Active on
Power On
7th transformation, parameters 1 to 10
790 - 799
Default value Lower input limit Upper input limit Units
0 -99 999 999 99 999 999 units (IS)
Active on
Power On
8th transformation, parameters 1 to 10
800 - 809
Default value Lower input limit Upper input limit Units
0 -99 999 999 99 999 999 units (IS)
Active on
Power On
The transformation parameters are required for the 2D/3D coordinate transformation. Refer to
NC MD 5060 to 5069 and Section Functional Descriptions for more detailed information.
MD 739, 749, 759, 779, 789, 799, 809, axes numbers for G96.
Only values for defined fictitious axes are permitted for these MDs. Any other values lead to
undefined behaviour of formation with G96.
_______
* For more detailed information about parameters 1-10 see the Installation Lists.
6–28 ©
Siemens AG 1992 All Rights Reserved 6FC5197- AA50
SINUMERIK 840C (IA)
