Siemens SINUMERIK 840C - Page 212

07.97 6 NC Machine Data (NC MD), NC Setting Data (NC SD)
6.2 General machine data (general data)
2nd MCS offset in Z coordinates (as from SW 6)
339
Default value Lower input limit Upper input limit Units
0 0 99 999 999 MS
POWER ON
Note:
For further information see description of the function collision monitoring.
3rd MCS offset in X coordinates (as from SW 6)
340
Default value Lower input limit Upper input limit Units
0 0 99 999 999 MS
POWER ON
Note:
For further information see description of the function collision monitoring.
3rd MCS offset in Y coordinates (as from SW 6)
341
Default value Lower input limit Upper input limit Units
0 0 99 999 999 MS
POWER ON
Note:
For further information see description of the function collision monitoring.
3rd MCS offset in Z coordinates (as from SW 6)
342
Default value Lower input limit Upper input limit Units
00 MS
POWER ON
Note:
For further information see description of the function collision monitoring.
4th MCS offset in X coordinates (as from SW 6)
343
Default value Lower input limit Upper input limit Units
0 0 99 999 999
POWER ON
Note:
For further information see description of the function collision monitoring.
4th MCS offset in Y coordinates (as from SW 6)
344
Default value Lower input limit Upper input limit Units
0 0 99 999 999
POWER ON
Note:
For further information see description of the function collision monitoring.
4th MCS offset in Z coordinates (as from SW 6)
345
Default value Lower input limit Upper input limit Units
0 0 99 999 999
POWER ON
Note:
For further information see description of the function collision monitoring.
©
