Siemens SINUMERIK 840C Installation Instructions

6 NC Machine Data (NC MD), NC Setting Data (NC SD) 09.95
6.7.1 Axis-specific MD 2 (axial data 2)
Exact stop limit fine 2nd - 8th parameter set
1568*-
1592*
Default value Lower input limit Upper input limit Units
10 +0 16 000 units (MS)
10 +0 99 999 999 (as from
SW 4.4)
units (MS)
Active on
NC Stop
These MD have the same meaning as MD 208*, see also ”Functional Descriptions: Parameter
set switchover”.
Zero speed monitoring 2nd - 8th parameter set
1596*-
1620*
Default value Lower input limit Upper input limit Units
100 0 16 000 units (MS)
100 0 99 999 999 (as from
SW 4.4)
units (MS)
Active on
NC Stop
These MD have the same meaning as MD 212*, see also ”Functional Descriptions: Parameter
set switchover”.
P component compensatory controller 2nd - 8th parameter
set (as from SW 4)
1624*-
1648*
Default value Lower input limit Upper input limit Units
0 0 16 000 1
Active on
RESET
These MD have the same meaning as MD 1420*, see also ”Functional Descriptions:
Parameter set switchover”.
I component compensatory controller 2nd - 8th parameter
set (as from SW 4)
1652*-
1676*
Default value Lower input limit Upper input limit Units
0 0 16 000 1
Active on
RESET
These MD have the same meaning as MD 1424*, see also ”Functional Descriptions:
Parameter set switchover”.
D component compensatory controller 2nd - 8th parameter
set (as from SW 4)
1680*-
1704*
Default value Lower input limit Upper input limit Units
0 0 16 000 1
Active on
RESET
These MD have the same meaning as MD 1428*, see also ”Functional Descriptions:
Parameter set switchover”.
6–178 ©
Siemens AG 1992 All Rights Reserved 6FC5197- AA50
SINUMERIK 840C (IA)
