09.95 6 NC Machine Data (NC MD), NC Setting Data (NC SD)
6.7 Axis-specific MD 2 (axial data 2)
Application:
A gearbox grouping can be configured with the G401 command. If the type of link has not
been defined in the G401 command, the default value from MD 1456* is taken.
Example:
G401 X Y Z
X, Y: leading axes, Z: following axis, no link type.
If "No default" (MD 1456* = 0) has been entered and no link type has been entered in G401,
reset alarm "GI CONFIGURATION illegal" is triggered.
Time constant symmetrizing filter 3rd - 8th parameter set
(as from SW 4)
1460*-
1480*
Default value Lower input limit Upper input limit Units
0 +0 1 000 0.1 ms
Active on
NC Stop
These MD have the same meaning as MD 392*, see also ”Functional Descriptions: Parameter
set switchover”.
Time constant setpoint filter 2nd - 8th parameter set
(as from SW 4)
1484*-
1508*
Default value Lower input limit Upper input limit Units
0 0 1 000 0.1 ms
Active on
at once
These MD have the same meaning as MD 1272*, see also ”Functional Descriptions:
Parameter set switchover”.
Scaling factor max. velocity 2nd - 8th parameter set
(as from SW 4)
1512*-
1536*
Default value Lower input limit Upper input limit Units
10 000 1 99 999 999
mm inch degr.
–––– –––– ––––
min min min
Active in
channel of
mode group
in STOP
These MD have the same meaning as MD 256*, see also ”Functional Descriptions: Parameter
set switchover”.
Exact stop limit coarse 2nd - 8th parameter set
(as from SW 4)
1540*-
1564*
Default value Lower input limit Upper input limit Units
40 +0 16 000 units (MS)
40 +0 99 999 999 (SW 4.4
and higher)
units (MS)
Active on
NC Stop
These MD have the same meaning as MD 204*, see also ”Functional Descriptions: Parameter
set switchover”.
©
Siemens AG 1992 All Rights Reserved 6FC5197- AA50
6–177
SINUMERIK 840C (IA)
