7 Drive Machine Data (SIMODRIVE Drive MD) 04.96
7.3.2 Drive MD (data description)
Firmware date
1798
Default value Lower output limit Upper output limit Units
0 0 32 767 –
Active
at once
Output of coded software version in decimal notation. The software version is output in the
following form: DDMMY, where DD = day, MM = month and Y = last digit of the year.
Example: 01.06.1993 ˆ= 01063
dec
Firmware version
1799
Default value Lower output limit Upper output limit Units
0 0 32 767 –
Active
at once
Output of present software version in decimal notation, e.g. 21000. The latter corrresponds to
version 2.10/00.
Drive machine data MSD: 2nd motor
Drive machine data, MSD for 2nd motor are listed below.
They only differ from the 1st motor by a number, not in their meaning:
• the first number is 2.
Example
MD 1005 No. of encoder marks motor measuring system 1st motor
MD 2005 No. of encoder marks motor measuring system 2nd motor
The meaning of the MDs of the 2nd motor are identical to the MDs of the same name of the
1st motor: see description for 1st motor.
MD No. Motor 2 Title MD No. Motor 1
2005 No. encoder marks motor measuring system 1005
2102 Motor code number (up to SW 4) 1102
2103 Motor rated current 1103
2117 Motor moment of inertia 1117
2119 Inductance of series reactor 1119
2120 P-gain current controller 1120
2121 Integral-action time current controller 1121
2125 Ramp-up time 1 for V/f operation 1125
2126 Ramp-up time 2 for V/f operation 1126
2127 Voltage when f=0 V/f operation 1127
2129 cos phi power factor 1129
2130 Motor rated power 1130
7–164 © Siemens AG 1992 All Rights Reserved 6FC5197- AA50
SINUMERIK 840C (IA)
