4-58
1010GCNFM-3C
Section 4
To assign a function for the current output:
1. From the [Analog Out Setup], press the <Right Arrow> twice to access the [Io] option list.
2. Press the <Up or Down Arrow> to move the cursor to the desired data function.
3. Press <ENT> To store selection.
Assigning Vo Output Functions
The Vo analog output is a 0-10V DC signal that varies linearly in relation to a selected function.
To assign a function to the voltage output:
1. Press the <Right Arrow> to access the [Vo] option list.
2. Press the <Up or Down Arrow> to move the cursor to the desired data function.
3. Press <ENT> To store selection.
Assigning Pgen Output Functions (see tables below for wiring)
The Pgen analog output is a pulse rate signal whose configuration is detailed in Installation Drawing
1010N-7. It varies linearly from 0-5000 Hz in relation to a selected data function. (Note: For Custody
Transfer flowmeters the Analog Pgen is replaced by the Digital Pgen option.)
To assign a function to the Pgen output:
1. Press the <Right Arrow> to access the [Pgen] option list.
2. Press the <Up or Down Arrow> to move the cursor to the desired data function.
3. Press <ENT> To store selection.
PULSE OUTPUT (Pgen Wiring)
FUG1010GCN & FUG1010GCDN with 1010N-2 Modules
Installation Drawing 1010N-2-7 (Sheet 2 of 2)
PIN# SIGNAL FUNCTION NOTES
11 PGEN 1+ FREQUENCY OUTPUT 1 0 - 5000 Hz, 5 Volt Logic, Square Waveform
12 PGEN 1- REF. GROUND
13 PGEN 2+ FREQUENCY OUTPUT 2
14 PGEN 2- REF. GROUND
FUG1010GCN & FUG1010GCDN with Expanded 1010N-7 I/O Modules
Installation Drawing 1010N-7-7 (Sheet 2 of 3)
(Standard, High Performance and Enhanced Performance Flowmeters)
PIN# SIGNAL FUNCTION NOTES
9 PG1 FREQUENCY OUTPUT 1 0 - 5000 Hz, 5 Volt Logic, Square Waveform
10 PG2 REF. GROUND
11 PG3 FREQUENCY OUTPUT 2
12 PG4 REF. GROUND
FUG1010GCCDN (Expanded 1010N-7 I/O Module)
Installation Drawing 1010N-7-7 (Sheet 3 of 3)
(Ultra Performance Flowmeters)
PIN# SIGNAL FUNCTION NOTES
9 PG1 PRIMARY FREQUENCY OUTPUT / OPEN COLLECTOR Digitally Synthesized
10 PG2 PRIMARY FREQUENCY OUTPUT / TTL Pulse Waveform
11 PG3 QUADRATURE FREQUENCY OUTPUT / OPEN COLLECTOR
12 PG4 QUADRATURE FREQUENCY OUTPUT / TTL
TB2
TB2
TB2
