3-1
1010GCNFM-3CSection 3
3. GETTING STARTED
3.1 THE KEYPAD ENABLE SWITCH
FUG1010GCN models with integral keypads provide a keypad enable/disable switch to prevent unau-
thorized access to the Installation Menu. In addition, a password entry option is available (see paragraph
4.1 Channel Setup Menu). The keypad enable/disable switch is located inside the lockable enclosure
right above the I/O wiring terminal. Please switch to the enable position before proceeding further. If
necessary, see drawings 1010GCN-7 or 1010GCDN-7 for location.
3.2 THE FUG1010GCN KEYPAD
The FUG1010GCN integral keypad provides 32 numeric and function keys (see table below). Use these
keys to enter, review or edit the site data. Certain keys control the graphics display,
KEY USAGE
KEYPAD FUNCTION CHART
MENU Press to activate the Installation Menu.
ENT Press <ENT> to store numeric data, select from option lists, etc.
LEFT, RIGHT ARROWS Menu navigation keys move cursor in respective directions.
UP, DOWN ARROWS Same as <Left> and <Right>. Also scrolls option list and graphic
display screen.
CLR Clear Key for erasing data, or selecting list options.
NUMBERS 0-9 Use to type numeric data.
DECIMAL POINT Use for decimal points in numeric data.
MATH OPERATORS Allows 4-function math operations in numeric entry cells.
<F> KEYS 1-3 Totalizer control and special function keys.
<F4> KEY CAUTION: SYSTEM RESET KEY (during power up)
CTL & ALT Used as shift keys for alternate key functions.
DATALOG Triggers immediate Datalogger report.
PLUS/MINUS [+/-] Changes the sign of numeric data.
NOTE: The keypad does not have alphabetic keys. Scrolling lists provide alpha-numeric charac-
ters as needed.
