4-67
1010GCNFM-3C
Section 4
NOTE: Pressing the <Left Arrow> at any stage prior to accepting the measured value will abort
the installation and return to the previous setting.
To access this [HF] menu item proceed as follows:
z At the [Meter Type] Menu, press the <Right Arrow> and then <ENT> to select the desired Path
(e.g., Dual Path Flow).
z In the [Dual Path Flow] Menu, press the <Down Arrow> and scroll to the [Diagnostic Data] menu
cell. Press the <Right Arrow> to select it.
z In the [Diagnostic Data] Menu, highlight [Path Select] and select the desired transducer path.
Press <ENT> to select path.
z Press the <Down Arrow> and scroll to the [Site Setup Data] menu cell. Press the <Right Arrow>
to select it.
Siemens Dual Path 4SS10G
Access Path/Channel Diagnostic Data
Channel /Path Setup
Pipe Data
Gas Parameters
Pick/Install Xdcr
Operation Adjust
Flow/Total Units
Data Span/Set/Cal
Stripchart Setup
Datalogger Setup
I/O Data Control
Diagnostic Data
Dual Path Flow
Siemens Dual Path 4SS10G
Transducer Setup Data
Path Select 1
Path Enable Yes
Flow Rate
Application Info
Gas Data
Site Seup Data
Test Facilities
Print Site Setup No
Date Site Created: 04.09.0314.52.23
Diagnostic Data
“Manual” Adjustment Procedure
z In the [Site Setup Data] Menu, press the <Down Arrow> and scroll to the [HF] menu cell. Press
the <Right Arrow> and a pop-up [Manual] prompt will appear as shown below. Note: Press the
<Up/Down Arrow> to select [Automatic], if desired.
z Use the numerical keys to input the desired correction value. Press <ENT> to input value.
fx (drive) 29
N (burst length) 5
Ltn in 5.316
Vf max CU Adjustment
Vs max m/s >Manual
Vs min m/s 1355.00
Samples/Cycle 29
Max Damping
Min Damping
HF >-0.000
Siemens Dual Path 4SS10G
Site Setup Data
fx (drive) 29
N (burst length) 5
Ltn in 5.316
Vf max CU >Manual
Vs max m/s = -0.120
Vs min m/s 1355.00
Samples/Cycle 29
Max Damping
Min Damping
HF >-0.000
Siemens Dual Path 4SS10G
Site Setup Data
