4-8
1010GCNFM-3C
Section 4
ENT
The default pipe configuration (Fully Developed) wll cause the flowmeter to use the conventional Reynolds
Compensation Table when compensating for liquid flow profile behavior.
To highlight the desired piping configuration press
To register selection press
Pipe Data Pipe Configuration Fully Developed*
(Change to Upstream 1 Elbow
Piping) Dbl Elbow +
Dbl Elbow -
Valve
Expander
Reducer
Norm Entry
Header Inlet
Intrusions
Anomaly Diams xxxx (numeric entry)
Ö
Ú
Ö
Pipe Configuration Menu Structure
* Default
Ú
Ú
Ö
Use this menu cell to enter the
number of pipe diameters
between the upstream
configuration and the
transducer installation.
Use this menu cell to select
the pipe configuration that
most accurately represents
the upstream pipe condition.
Siemens Dual Path [1] Path 1
Disignate Pipe Shape Near Transducers
Select Path 1
Select Pipe Class Manual Entry
Select Pipe Size No Pipes
Pipe OD <in> 6.625
Pipe Material Steel
Wall Thickness 0.250
Pipe ID
CC129 Thickness
Pipe Configuration Fully Developed
Anomaly Diams. 1 Elbow
ThermExp Coef 1/F Dbl Elbow +
Mod of Elast PSI Dbl elbow -
Valve
Pipe Data
PIPE CONFIGURATION OPTION LIST DEFINITIONS
Fully Developed Fully Developed flow, as would be expected for very long straight pipe runs or
installation downstream of a flow condition.
1 Elbow Single 90 degree Elbow upstream of transducer installation.
Dbl Elbow + Double out-of-plane Elbows upstream of transducer installation.
Dble Elbow - Double in-plane Elbows upstream of transducer installation.
Valve To Be Determined.
Expander Pipe expansion upstream of transducer installation.
Reducer Pipe reduction upstream of transducer installation.
Norm Entry To Be Determined.
Header Inlet Header or pipe manifold upstream of transducer installation.
Intrusions To Be Determined.
To Next Page
