3-5
1010GCNFM-3CSection 3
Pressing the <Right Arrow> again accesses the option list. This expands the reverse video highlight to
show the list contents. Note that a cursor (arrow) points to the top item on the list.
The <Up and Down Arrows> scroll option lists in their respective directions. Every press moves the
cursor to the next item in sequence. Due to the size of the display screen, some option lists include more
items than those shown on the initial display. In which case you arrive at the last item on a list and the
next <Down Arrow> press brings you back to the top of the list. This is because the option lists are of the
“wrap-around” type.
To select an option list item, move the cursor to the item and then press the <ENT> key. This places your
selection at the top of the list and moves you out of the option list to the next menu cell. The option list
item: [Ft/Sec <vel>] has been selected. Note that this appears on the right-hand column and that the
reverse video highlight area moves to the next menu cell in sequence: [Std Flow Corr].
Siemens Dual Path SITE 1
Flow Volume Units >Cubic Feet
Std Flow Corr Cubic Inches
Flow Time Units Cubic Meters
Flow Display Range Pounds
Flow Display Scale Kilograms
Total Volume Units Tons
Totalizer Scale Metric Tons
Total Resolution Ft/Sec (Vel)
Totalizer Mode M/Sec (Vel)
Batch/Sample Total 0.000
Flow/Total Units
Choose desired Flow rate volume units
Multiple Select Option Lists
Certain option lists allow you to make more than one selection. For example, the [Datalogger Data]
option list allows you to select any or all of the available data items for your reports. As previously
described, you can use the <Up and Down Arrows> to move the cursor through the list. However, if you
press <ENT> to select an item, a plus sign (+) appears next to that item. The cursor remains within the
option list so that you can make other selections. To deselect a previously selected item, move the cursor
next to that item and then press <CLR>. You use the <Left Arrow> to leave a multiple select option list.
Siemens Dual Path SITE 1
Flow Volume Units Ft/Sec <vel>
Std Flow Corr No
Flow Time Units SEC
Flow Display Range Autorange
Flow Display Scale Ft/SEC
Total Volume Units Cubic Feet
Totalizer Scale KCU FT
Total Resolution 00000x00
Totalizer Mode NETFLOW
Batch/Sample Total 0.000
Flow/Total Units
To Next Page
