4.1 THE CHANNEL/PATH SETUP MENU
The Channel/Path Setup Menu is available after picking a meter type and a measurement technology.
Use this menu to manage site setups. You can create, recall, delete and save entire site setups. You can
apply Site Security, which permits read-only access to the Installation Menu unless you enter a password.
The [Channel Enable] menu cell allows you to disable and enable a measurement channel. Be aware
that site name option lists only show sites that are consistent with the currently selected meter type.
This shows that
the Meter Type is
Dual Path,
operating with
Path 1 active.
Channel Setup Recall Site Setup *Site Name List
Channel Enable Yes
No
Create/Name Site *Site Name Entry/Edit
Site Security Off
On
Delete Site Setup Site Name List
Save/Rename Site *Site Name Entry/Edit
Ö
Ú
Ö
Ö
Ö
Ö
Ö
Ú
Ú
Ö
Ö
Ö
Ö
Ö
CHANNEL SETUP MENU STRUCTURE
Ö
