4-62
1010GCNFM-3C
Section 4
4.11.1 MAIN DIAGNOSTICS SCREEN
This is the main Diagnostics Data screen. It provides menus that show Flow, Application, Gas Data and
Site Setup information. In addition, the Test Facilities menu provides test/control functions to optimize
operation, analyze application conditions and to recover system operation. As shown below, diagnostics
provides five menus and two menu cells:
4.11.2 FLOW DATA MENU
This menu provides a “live” display of all primary output data.
Siemens Dual Path SITE1
Current Flow Rate and Units
Flow Data
Flow KCU FT/HR -0.05
Flow Vel F/S -0.60
Total KCU FT 3.2895
Vs m/s 334.79
Signal mV 10.8
Valc % 56
Vtrb 0
Alarm Status -------------
AnCal KCU FT/HR 0.000
Siemens Dual Path SITE1
Real-Time flow-related data
Diagnostic Data
Path Select 1
Path Enable Yes
Flow Data
Application Info
Gas Data
Site Setup Data
Test Facilities
Print Site Setup No
Date Site Created: 07.17.01 13.47.36
Flow Data This menu shows flow rate, total and alarm data.
Application Info This menu shows current meter operating status.
Gas Data This menu shows current Reynolds #, measured temperature and pressure as
well as molecular weight and computed volume correction.
Site Setup Data This menu shows current transducer setup data and signal status.
Test Facilities This menu provides system test and recovery routines.
Print Site Setup This Menu cell allows you to send an ASCII dump of the current Site Data to a RS-
232 port device (e.g., a printer or laptop computer).
Date Site Created This menu cell shows the date and time when the current site was created.
MAIN DIAGNOSTIC MENU DESCRIPTION
