4-21
1010GCNFM-3C
Section 4
4.4.1 HOW TO SELECT A TRANSDUCER MODEL
Use the [Transducer Model] menu cell to define the type of transducer for use with your application. This
allows the flowmeter to adjust its transmit/receive functions accordingly. You can choose from either the
[1011G Universal] or [1011HG High Precision] transducer lists.
You should consider using 1011 high precision transducers for most gas metering applications. 1011
Universal transducers should only be used when the wall thickness of the pipe exceeds the limit of the
1011 High Precision transducers or when the diameter to wall thickness is considered too small. The
system default is [1011G Universal]. If this suits the application, bypass this menu cell by pressing the
<Down Arrow>.
Pick/Install Xdcr Install Path 1
2
Transducer Model 1011G Universal
1011HG Hi Precision
Transducer Size 1011G Universal 1011HG High Precision
A1 A1HA1H
A2 A2H
B1 A3H
B2 B1H
B3 B2H
C1 B3H
C2 C1H
C3 C2H
D1 D1H
D2 D2H
D3 D3H
E1 D4H
E2
E3
Xdcr Mount Mode Direct
Reflect
Spacing Offset Minimum
Nominal
Maximum
Number Index 4 (generated)
Spacing Method Spacer Bar [P/N]
*
auto P/N generation
Ltn Value <in> 2.00 (generated)
Install Completed? No *[Yes] indicates successful install
Install
Zero Flow Adjust AutoZero
ZeroClr
Reversamatic
Actual Zero
ZeroMatic* *Reflect mount only
Ú
Ö
Ö
Ö
Ö
Ú
Ú
Ú
Ú
Ú
Ú
Ú
Ö
Ö
Ö
Ö
Ö
Ö
Ú
Ú
Ú
Ú
Ö
PICK/INSTALL XDCR MENU STRUCTURE
Ú
Ú
Ú
To Next Page
