3-3
1010GCNFM-3CSection 3
3.4 HOW TO USE THE INSTALLATION MENU
This section introduces the FUG1010GCN Installation Menu. It explains how to access and leave the
Installation Menu and how to enter site data. The Installation Menu consists of sub-menus, each provid-
ing individual menu locations (menu cells) that store site data. For convenience, this manual refers to
sub-menus simply as menus (e.g., the Gas Parameters Menu). Shown below is the setup screen for
Channel 1 of a dual-channel meter. Single channel systems are identical but some sub-menus will be
similiar to Dual Path menus.
Please do not let the size of the Installation menu intimidate you. Almost all menu cells already contain
default parameters. To begin operation, you only need to access the menu cells that control a required
parameter, such as the [Pick/Install Meter]. You will see that by accepting most defaults, you can set up
the meter in about five minutes.
Siemens Dual Path SITE 1
Channel/Path Setup
Pipe Data 7.900
Gas Parameters
Pick/Install Meter
Operation Adjust
Flow/Total Units
Data Span/Set/Cal
Stripchart Setup
Datalogger Setup
I/O Data Control
Diagnostic Data
Clamp-on Gas
Create-Name-Recall-Enable & Delete Site
3.4.1 ACCESSING AND LEAVING THE MENU
Upon first turning the meter on you see a Siemens graphic. This means that there is no active site setup
currently stored in memory. Note that this screen identifies the software version of the meter on the
upper right-hand corner of the display.
Make sure the keypad enable switch is in the correct position then press the <MENU> key to select the
menu. The first time you access the Installation Menu, you can leave it only by saving a site or by turning
the flowmeter off. After installing and activating a site, use the <MENU> key to toggle between a graphic
display screen and the last accessed menu location.
ver. 3.01.00
Software
Version
(x.xx.xx)
To Next Page
