4-61
1010GCNFM-3C
Section 4
4.11 THE DIAGNOSTICS DATA MENU
Some Diagnostic Data items require a successful transducer installation and meter initialization
to become available. These will report [Chan Not Setup] until you complete the installation pro-
cedure. The Diagnostics Data menu provides real-time application and setup data, plus test routines for
the selected channel. To receive the best technical support, please be prepared to report any diagnostic
data item upon request. Note also that these menus contain information that may only be meaningful to
our technical support staff. The available diagnostic data depends on the flowmeter type and channel
configuration. All diagnostic items are available when you select [Dual Path Flow] for [Path 1] or [Path 2].
Some items are not available (N/A) when you select virtual channel [1 and 2].
Diagnostic Data Path Select 1
2
1 and 2
Path Enable Yes/No
Flow Data Flow
Flow Vel F/S
Total
Vs m/s
Signal mV
Valc %
Vtrb %
Alarm Status
Ancal
Application Info TN uSec
TL uSec
DeltaT uSec
Burst/Sec
% Accepted
Last Makeup
Makeup Status
Gas Data TEMP 1
TEMP 2
Reynolds #
Base S.G.
Specific Gravity
Temperature
Pressure
Volume Corr.
Viscosity cS
Site Setup Data fx (drive)
N (burst length
Ltn in
Vfmax
Vs max m/s
Vs min m/s
Samples/Cycle
Max Damping
Min Damping
HF
Test Facilities Makeup
Graph
Tx Up
Tx Dn
Fixed ALC
Tx Up Fixed ALC
Tx Dn Fixed ALC
Graph AutoZero
Print Site Setup No/Yes
Date Site Created: xx.xx.xx xx.xx.xx
Ú
Ú
Ú
Ú
Ú
Ú
Ö
Ö
Ö
Ö
Ö
DIAGNOSTIC DATA MENU STRUCTURE
Ö
Ö
Ö
Ö
Ö
Ö
Ö
Ú
Ú
Ú
Ú
Ú
Ö
ÖÖ
Ú
Ö
Ö
Ú
To Next Page
