3-4
1010GCNFM-3CSection 3
When you press the <MENU> key, the cursor arrives at the first level of the Installation Menu. Refer to the
sample screens below. The left screen is from a dual-path model. Note that two columns, one on the left-
hand side and the other on right-hand side, divide the screen. The first left-hand item, [Meter Type], is
highlighted (white type on black). The next left-hand selection is [Meter Facilities]. Use the [Meter Facili-
ties] menu to set global meter options and controls.
3.4.2 HOW TO ENTER DATA
The left-hand column shows the menu cells (described previously). Another way to think about left-hand
column items is to consider them menu questions. Then you can see that the right-hand column an-
swers these questions. Right-hand column answers can be:
z Another series of menu cells (may become left column items when selected).
z An item from a scrollable option list.
z A numeric entry.
z An alphanumeric string (e.g., a site name).
Selecting Items from an Option List
This example shows how to use an option list to select the preferred flow units for your application. Do
not worry about how to access this menu right now. That will be explained later. Examine the screen
below. Note that the menu name [Flow/Total Units] appears in reverse-video text on lower left of the
screen. Note also that a reverse video bar highlights the menu cell [Flow Volume Units] and the right-
hand column shows the current default [Cubic Feet].
Siemens Dual Path SITE 1
Top menu screen for dual-path system
Select Meter Type
Meter Facilities
Meter Type > Dual Path Flow
Siemens Dual Path SITE 1
Flow Volume Units Cubic Feet
Std Flow Corr No
Flow Time Units HR
Flow Display Range Autorange
Flow Display Scale KCU FT/HR
Total Volume Units Cubic Feet
Totalizer Scale KCU FT
Total Resolution 00000x00
Totalizer Mode NETFLOW
Batch/Sample Total 0.000
Flow/Total Units
Choose desired Flow rate volume units
