Manual Addendum
1010FMA-56
Operating System Software Version Update
INTRODUCTION
The following software operating system version update is for Version 3 flowmeters. Please refer to
this addendum when using this technical manual with Version 3 operating system software and
flowmeters that have been updated to Version 5.
Operating System Software Changes
1. The [Meter Type Menu] includes a [Language] menu item that allows the selection of multiple flowmeter
menu foreign languages.
2. Version 3 and Version 5 Operating System Differences
The following table lists the differences between Version 3 and Version 5 operating system menu
items and menu hint lines.
A-1
Version 3 Version 5
Select Pipe Class Pick Pipe Class
Pick/Install Xdcr Install Xdcr
Data/Span/Set/Ca Span/Set/Cal
Strip Chart Setup Display Setup
Dual Channel Flow 2 Channel Flow
Dual Beam Flow Dual Path Flow
Datalogger Setup Logger Setup
Temperature Range Temp Range
Pipe Configuration Pipe Config
Datalogger Setup Logger Setup
Datalogger Mode Logger Mode
Datalogger Data Logger Data
Log Time Interval Logger Interval
Display Datalogger Display Logger
Recall Site Setup Recall Site
Delete Site Setup Delete Site
Install Completed? Install Complete
Estimated Vs m/s Estimated Vs M/S
Channel /Path Setup Channel Setup
Reflexor Zero Fault/Set Zero Fault/Set
Memory Delay (sec) Memory Delay s)
Flow Volume Units Flow Vol. Units
Flow Display Range Flow Disp. Range
Flow Display Scale Flow Disp. Scale
Total Volume Units Total Vol. Units
Batch/Sample Total Batch/Sample Tot
Calibrate Flowrate Calib. Flowrate
Analog Input Setup Analog Inp Setup
Flow Vel F/S Velocity F/S
Vs m/s Vs M/S
Valc % Valc
Vaer % Vaer
Vs Max m/s Vs Max M/S
(continued )
