NOTE: Some transducers require a right-angle adapter. This adapter should be installed before
placing the transducer in the tracks.
10. Connect the transducer cable, ensuring that you have observed the Upstream/Downstream ori-
entation in respect to the cable and the input jack on the flowmeter. If this is a dual-channel unit,
make sure you are connecting the cables to the correct channel input jacks.
Notice: Siemens holds US Patent Number 4,929,368 on the CC#122 Coupling Compound and all
compounds of this type. Its use is restricted to Siemens products only, unless a special
license has been obtained. Licenses for use with other products are available through the
Siemens Sales Department.
ITEM CC# USE CHARACTERISTICS
1 101 Temporary and portable use on Clamp-on Low in halogens and
flow transducers. Temp. range: -40°F to 100°F. sulfur content.
2 102 Temporary and portable use for all Clamp-on flow Low in halogens and sulfur
transducers. Well suited for survey use. content. Water soluble.
Temp. range: -30°F to 100°F.
3 109 Temporary and portable use for all Clamp-on Low viscosity Petroleum
flow transducers. Temp. range: -40°F to 300°F. product.
4 110 High temp. temporary couplant to be used when Resists breakdown and
setting up high temp. plastic flow transducers. thinning out at high temper-
Temp. range: 255°F to 450°F. atures.
5 111 Permanent high temp. couplant for plastic flow Room temperature vulcanizing
transducers. Temp. range: 255°F to 450°F. silicone rubber.
6 112 Permanent ambient temperature couplant for Room temperature vulcanizing
plastic flow transducers. Temp. range: -40°F silicone rubber.
to 250°F.
7 113 Protective spray for providing corrosion resistance Spray on liquid. Excellent
to exposed transducer and track parts. resistance to salt water
atmosphere.
8 114 Temporary and long term couplant for all flow Teflon filled grease.
transducer types. Temp. range: -40°F to 255°F. Water resistant.
9 117 Long term and permanent couplant for Clamp-On Silicone grease loaded with
transducers. Temp. range: -40°F to 450°F. metal oxides. Resists Break-
down and thinning at high
temperatures.
10 120 Submersible couplant. To be used on all submer- Extremely water resistant.
ged transducer applications. Consult Controlotron before
using.
11 122 Long term and permanent couplant for Clamp- Long chain polymer grease.
on transducers. Temp. range: -40°F to 450°F. Resists breakdown and thin-
ning at high temperatures.
12 124 Long term and permanent couplant for Clamp-On Two part room temperature
transducers. Temp. range: -40°F to 250°F. cure adhesive.
13 128 Temporary and long term couplant for all flow High viscosity silicone
transducer types. Temp. range: -40°F to 375°F. grease. Water resistant.
14 129 Adhesive backed Dry/Damping couplant for all flow Viscoelastic polymer sheet.
129A transducer types. Water resistant.
RECOMMENDED SONIC COUPLING COMPOUNDS
