Selecting Sensor Mounting Location
Select a sensor mounting location that has a fully developed flow profile. Do not locate the
sensor so that sonic energy enters a region that is not representative of the flow velocities at
the measuring location.
Use the figure below as a guide to select the proper mounting location.
① Elbow ③ Valve
② Expansion or Contraction ④ Orifice Plate
Figure 7-1 Sensor Mounting Examples
Functions
7.11 Reflexor
FUP1010 IP67 Portable Flowmeter
98
Operating Instructions, 02/2010, A5E02951522A Revision 01
