1011 Universal series sensors and mounting frames have the following color codes for easy
identification:
● Gold - size 'A'
● Blue - size 'B'
●
Red - size 'C'
● Green - size 'D'
● Black - size 'E'
Note
Check to make
sure that the sensors are a matched set with the same serial numbers and
marked with an "A" and "B" (e.g., 19256A and 19256B).
Note
Sensor
Model names
for Version 3 op systems are as follows: 1011H Hi Precision, 1011
Universal and 991 Universal.
Sensor Selection
Note
The transmitter must be powered up before you can select a sensor model. Refer to
Transmitter Wiring (Page 23).
Before selecting sensors proceed to Setting the Parameters (Page 33) and perform the
preliminary programming procedures.
5.2.3 Setting the Parameters
Select Language and Units
Note
Before creating a site select a language and then English or Metric units from the Meter
Facilities menu.
To select English or metric units:
1.
In Meter Type Menu, scroll to Meter Facilities Menu. Press <Right Arrow> and select
preferred units.
2.
Press <ENT> to select. Press <Left Arrow> and <Up Arrow> to return to main menu.
Connecting
5.2 Sensor Wiring
FUP1010 IP67 Portable Flowmeter
Operating Instructions, 02/2010, A5E02951522A Revision 01
33
