Commissioning
6
6.1 General requirements
Before commissioning it must be checked that:
● The device has been installed and connected in accordance with the guidelines provided
in chapter 4 "Installing / Mounting
(Page 19)" and 5 "Connecting (Page 23)"
6.2 Commissioning
WARNING
Certain parts inside the transmitter carry dangerous high voltage.
CAUTION
Confirm that one of the following power sources is connected: internal battery pack, external
battery pack or Power Adapter / Battery Charger.
1. Apply power.
2. Within 10 seconds
of power-up the main display will become active and a typical Siemens
graphic will appear briefly. The screen also identifies the software version of the unit as
shown below.
① Software operating system version
FUP1010 IP67 Portable Flowmeter
Operating Instructions, 02/2010, A5E02951522A Revision 01
65
