Description
3
3.1 FUP1010 features
Description
The Siemens SITRANS FUP1010 Weatherproof IP67 Portable flowmeters achieve highly
accurate flow measurements using ultrasonic transit-time technology. The sensors are
mounted on the
outside of the pipe, preventing contact with the medium. This means no cavities
or clogging by high paraffin liquids found in many hydrocarbon applications.
The sensors offer superior performance in terms of volumetric flow accuracy, density accuracy,
and turn-down ratio. The sensor construction makes installation and commissioning of even
the largest sizes very straight forward and easy.
The sensors deliver true multi parameter measurements i.e.: volume flow and temperature.
The flowmeter has a degree of protection of IP67.
Note
This operating Instructions manual applies to the following FUP1010 IP67 (weather proof)
operating systems: Version 3.02.00K and later and version 4.03.00 and later.
Portable Configurations
The FUP1010 weatherproof single and dual channel flowmeters use a compact and rugged
submersible, weatherproof case. The following portable models are available:
● FUP1010 Weatherproof Single Channel Multi-Function Portable
● FUP1010 Weatherproof Dual Channel/Dual Path Multi-Function Portable
Figure 3-1 Weatherproof Case-shown open
FUP1010 IP67 Portable Flowmeter
Operating Instructions, 02/2010, A5E02951522A Revision 01
11
