User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Displaying
parameter block
The constant parameters of
Displaying
block are:
–
Format
- the logical channel data formats, which are:
•
numeric
– value in this channel is displayed as a number,
•
binary
– only for values:
'0'
for low state and
'1'
for high state,
•
time
– value in this channel is displayed as a time. Logical channel in time
Format will always considers its value as a number of seconds and base on this
and settings in
Time pattern
parameter, the logical channel will calculate the
value to display,
–
Time pattern
– this parameter occurs only when
Format
parameter is set as
time
;
it allows user to define time pattern at his will. Only restrictions are that higher units
have to be before lower units and different units have to be separated by colon
character. Allowed is to create units which contains any number of digits. When user
creates a pattern which is forbidden, the device will detect it and set the pattern as
default.
–
Precision
– this parameter occurs when
Format
parameter is set as
numeric
or
time
, which specifies the precision to be displayed on the output value (see
Fig. 7.39
),
–
Off-state text
– this parameter occurs when
Format
parameter is set as
binary
,
when the input value is
≤ 0
the value is replaced by the text defined by the user,
default settings text is:
OFF
,
–
On-state text
- this parameter occurs when
Format
parameter is set as
binary
,
when the input value is
>0
the value is replaced by the text defined by the user,
default settings text is:
ON
,
The text of
Off-state
and
On-state
can be:
• text with black font such as: ALARM, off, OK,
• text using numbers and special characters such as: ALARM_ #12
• text using font color and / or a background color for example:
• no text, only a rectangle with the selected color - the width of the rectangle on
the screen is defined by pressing the
Spacebar
(empty string), and the color of
the rectangle is the background color, for example:
–
Digits
- this parameter occurs when
Format
parameter is set as
numeric
, allowing
user to choose the part of the number that is to be the value of the logical channel
displayed on the screen,
75
