PROCEDURE
DET Magnet Placement
1. Install the DET magnet approx. 2’ from the lower terminal landing
DZ magnet.
2. Perform the Learn function (see “Learning the Hoistway” section).
The hoistway has to be learned in order to run the car at full
Contract Speed.
3. After the learn is complete, run the car from the cartop inspection
station above the DET magnet. Remove the magnet and run the car
up to the next door zone above the bottom terminal landing. This
will allow the car to come to an emergency stop without going onto
the buffer.
4. Position the DET magnet on the tape opposite the DZ magnet.
5. Go to MAIN MENU | STATUS | MAGNETS | DZ MAGNET ## and
scroll to the floor the car is currently at. Record the TOP position
for the magnet.
Top: ____’ ____.____”
6. Run the car up to a door zone far enough above the magnet for a
full speed run.
To p: 2 2’06 . 87”
