125
7. From the machine room, enter a car call to the bottom terminal
landing, sending the car down towards the DET magnet at Contract
Speed (MAIN MENU | DEBUG | ENTER CAR CALLS).
8. As the car passes the DET switch it will get a “F81:DETS Overspeed”
fault and perform an emergency stop.
9. When the car comes to a complete stop, quickly switch the car to
Inspection (MR) before the controller resets and tries to correct
itself.
10. Record the position the car is currently stopped at from the
home screen of the LCD.
E-Stop Position: ____’ ____.____”
11. Subtract the position from where the car stopped at (Step
#10) from the known position of the DET magnet (Step #5). This will
be the actual slide distance of the car.
Slide Distance (SD): ____’ ____”
12. Position the DET magnet no less than the minimum distance
(refer to the Minimum Distance Equation). Measure from the
middle of the terminal landing DZ magnet up to the top of the DET
magnet.
In spect ion (MR) DZ
.. [ | ]PI : 3 T-14
13 40 20’11.25”
CMD: 0 FP M: 0
